Software 42481 Published by

The third beta of OBS Studio 30.2 is now available. The updated beta addresses a Windows crash while running OBS normally, as well as a memory leak issue.



OBS Studio 30.2 Beta 3

Beta 3 Changes

  • Fixed a crash in Beta 2 on Windows when running OBS normally (not in Portable Mode) [derrod]
  • Fixed a memory leak in Beta 2 [derrod]

Beta 2 Changes

  • Fixed a crash in Beta 1 when canceling a stream attempt with incompatible settings [palana]
  • Fixed a crash in Beta 1 related to WebSocket settings migration on systems set to non-English languages [tt2468]
  • Fixed a crash in Beta 1 where loading a theme could result in infinite recursion [derrod]
  • Fixed an issue in Beta 1 with Lua scripts not working on Linux [tytan652]
  • Fixed an issue in Beta 1 with the chapter marker hotkey setting not showing up [derrod]
  • Fixed an issue in Beta 1 where the Replay Buffer button text could be incorrect when trying to stop the Replay Buffer [gxalpha]
  • Fixed an issue in Beta 1 where a theme would override another theme with the same ID [tytan652]
  • Fixed an issue in Beta 1 where a warning dialog box for Multitrack Video errors would have untranslated buttons [RytoEX]
  • Clarified a warning message in Beta 1 when choosing a different GPU for NVENC [derrod]
  • Added detection for outdated Visual C++ Runtime which would cause a crash in Beta 1 [derrod]
  • Added detection in the Windows updater for outdated Visual C++ Runtime which would cause a crash in Beta 1 [derrod]
  • Made some UI adjustments from Beta 1 based on user feedback [Warchamp7]

30.2 New Features

  • Added support for Multitrack Video streaming [palana]
    • On Twitch, this is known as Enhanced Broadcasting. Currently, this requires Windows and an NVIDIA GPU. Support for other platforms and GPU vendors is planned. For more information, see:  https://help.twitch.tv/s/article/multiple-encodes
    • When this feature is enabled, the following data about your system will be sent to the streaming service when starting a stream:
      • OBS config info (canvas width and height, frame rate, encoder width and height, VOD Audio Track setting, OBS version)
      • CPU info (name, speed, core counts)
      • GPU info (model, memory, driver version, device ID, vendor ID)
      • Memory info (free, total)
      • OS info (name, version, arch, emulation)
        • Windows info (gaming feature status: Game Bar, Game DVR, Game Mode, Hardware-accelerated GPU Scheduling)
      • Multitrack Video settings (maximum streaming bandwidth, maximum video tracks)
  • Added support for Enhanced RTMP/FLV multi-track audio and video [palana/kc5nra]
    • Replaces the old metadata-based "VOD Track"
  • Added "Hybrid MP4" output format (BETA) [derrod]
    • Combines fault-tolerance of fragmented MP4 with wide compatibility and faster access times of regular MP4. For more information, see:  https://obsproject.com/kb/hybrid-mp4
    • Supports inserting chapter markers into the file via a hotkey or API. These markers are supported by most video players and editing software, such as DaVinci Resolve
  • Added Linux support to the native NVENC encoder [derrod]
    • NVENC AV1 is now supported on Linux
  • Added Linux shared texture support to the NVENC encoder [derrod]
  • Added Linux shared texture support to the QuickSync encoder [kkartaltepe]
  • Added Linux shared texture support to the VA-API encoder [nowrep]
  • Added HEVC support to WebRTC output [murillo128]
  • Added Composable Themes system to simplify theme creation, maintenance, and enable future customisation options [derrod/Warchamp7]

30.2 Changes

  • Various UI and Theme tweaks [Warchamp7]
  • Audio of multiple instances of a source in a scene/group is now deduplicated [derrod]
    • Deduplication is recursive, but does not apply on groups or nested scenes that are currently playing show/hide transitions, this may be fixed in the future
  • Scene Collection specific plugin data is now retained for plugins that are not currently loaded [derrod]
  • Closed-captions are now supported for HEVC and AV1 [jhnbwrs]
  • Qt Fusion style is now always enforced on Linux [tytan652]
  • Combined PipeWire window/display capture into unified "Screen Capture" source to align with other platforms [tytan652]
    • Renamed "Screen Capture (XSHM)" as "Display Capture (XSHM)" for consistency with other capture sources [tytan652]
  • Set default recording format on macOS to fragmented MOV [gxalpha]
  • Improved freetype2 text source performance [kkartaltepe]
  • File open dialogs now start in the directory of the currently selected file, rather than the default [Warchamp7]
  • Moved warnings in advanced output to bottom of settings window for better visibility [GPattenden]
  • Various performance improvements for texture encoding [kkartaltepe]
  • Prioritize NVDEC decoder on NVIDIA systems [moocowsheep]
  • Support NVDEC decoder for encoded DirectShow sources [moocowsheep]
  • Replaced non-texture NVENC FFmpeg fallback with native implementation [derrod]
  • Log now includes all available encoders [Penwy]
  • Reset duration of scene item show/hide transitions when removing the transitions [Warchamp7]
  • Adjusted appearance of volume meters [Warchamp7]
  • Adjusted appearance of multiview borders and labels [Warchamp7]
  • Added support for audio-only and video-only WHIP outputs [tt2468]

30.2 Bug Fixes

  • Fixed packet priority not being set for some AV1 encoders, resulting in outputs never recovering from dropping frames [derrod]
  • Fixed various issues with audio channel layouts in (remuxed) recordings [pkv/derrod]
  • Fixed various issues with the native FLV muxer [palana]
  • Fixed various issues with the RTMP protocol implementation [palana]
  • Fixed minor errors in HEVC and AVC decoder configuration records [derrod]
  • Fixed change discard confirmation dialog popping up twice when closing source properties [tytan652]
  • Fixed QSV AV1 on multi-GPU systems [thyintel/derrod]
  • Fixed FFmpeg output erroneously checking disk space when not writing to a file [RytoEX]
  • Fixed auto-config wizard not working without a stream key [mar10iana]
  • Fixed text alignment with extents [exeldro]
  • Fixed encoder properties having nested scroll areas in output settings [derrod]
  • Fixed crash if input video resolution changes when using hardware-accelerated decoding [tt2468]
  • Fixed button text being cut off in controls dock [powersagitar]
  • Fixed undo action for filters showing UUID instead of name [derrod]
  • Fixed not all eligible Patreon supporters being shown in the "About" dialogue [Warchamp7]
  • Fixed copy-pasting show/hide transitions not including duration [Warchamp7]
  • Fixed settings dialog being cut off on low-resolution screens [tytan652/Warchamp7/derrod/RytoEX] (yes, this one took four people to figure out)
  • Fixed paused indicator text stacking [Aleksbgbg]
  • Fixed disabled audio sources showing up in advanced audio properties [Penwy]
  • Fixed Grid Mode setting not being persisted when enabled through the View menu [RytoEX]
  • Fixed CoreAudio not handling encoder delay, resulting in audio being 44-48 ms late [derrod]
  • Fixed OBS not handling negative audio timestamps at the start of an output correctly, resulting in Opus and CoreAudio AAC audio being delayed by a few ms [derrod]
  • Fixed VA-API AV1 encoder being unavailable if H.264 is unsupported [kkartaltepe]
  • Fixed WebRTC buffer size being too small for recovery with high-bitrate video [Sean-Der]
  • Fixed renaming multiple scenes when hitting Tab key while renaming [howellrl]

Release OBS Studio 30.2 Beta 3 · obsproject/obs-studio
