This guide walks you through installing Envoy Proxy on Ubuntu 20.04 in a snap‑free, APT‑based way, starting with system updates and adding the official Envoy repository to keep your packages current. It then shows how to install Envoy, enable its systemd service, and verify that it’s running while pointing out common pitfalls like port conflicts that can cause the service to stay inactive. Next, you’re taken through a quick test by spinning up a Python HTTP server on 8080, editing a minimal YAML snippet to route traffic from listener 80 to that backend, restarting Envoy, and confirming the response with curl or a browser. Finally, the article hints at optional enhancements such as TLS or rate limiting, reminds you to check logs for problems, and wraps up by encouraging you to enjoy a production‑ready Envoy instance on your Ubuntu machine.

Installing Envoy Proxy on Ubuntu 20.04 in a Snap‑Free Way

If you’re still wrestling with that “I can’t get Envoy to start after the upgrade” problem, read on. You’ll walk through the exact commands that get Envoy up and running without any of the usual package‑manager headaches.

1. Prerequisites: A Fresh Server (or at least a clean terminal)

Open a terminal, drop into root mode, and make sure you have an updated system:

sudo apt update && sudo apt upgrade -y

An outdated apt cache can point you to old packages that won’t play nicely with the latest Envoy build.

2. Add the Official Envoy Repository

Envoy ships a dedicated APT repo that keeps things tidy. Grab the key and add the source:

curl -sL https://repo.solo.io/solo-apt-key.gpg | sudo gpg --dearmor -o /usr/share/keyrings/envoy-archive-keyring.gpg
echo "deb [signed-by=/usr/share/keyrings/envoy-archive-keyring.gpg] http://repo.solo.io/ubuntu focal main" | sudo tee /etc/apt/sources.list.d/envoy.list

Using the official repo means you’ll get the latest stable builds and security patches without waiting for Ubuntu’s backports.

3. Install Envoy

sudo apt update
sudo apt install envoy -y

Once installed, envoy will register as a systemd service automatically.

4. Verify the Service is Working

Start it (if not already running) and check status:

sudo systemctl start envoy
sudo systemctl status envoy

You should see a line like:

Loaded: loaded (/lib/systemd/system/envoy.service; enabled; vendor preset: enabled)
Active: active (running) since …

If the service shows inactive or failed, you’ve probably got a port conflict. I’ve seen folks run into that when their default Envoy config binds to 80 and Apache is still alive on the same port.

5. Test With a Simple Echo Service

Create a tiny HTTP server for traffic to hit:

python3 -m http.server 8080 &

Now point Envoy at it by editing /etc/envoy/envoy.yaml (or wherever your config lives). A minimal snippet:

static_resources:
  listeners:
    - name: listener_80
      address:
        socket_address: { address: 0.0.0.0, port_value: 80 }
      filter_chains:
        - filters:
            - name: envoy.http_connection_manager
              typed_config:
                "@type": type.googleapis.com/envoy.extensions.filters.network.http_connection_manager.v3.HttpConnectionManager
                stat_prefix: ingress_http
                route_config:
                  name: local_route
                  virtual_hosts:
                    - name: backend
                      domains: ["*"]
                      routes:
                        - match: { prefix: "/" }
                          route: { cluster: echo_service }
                http_filters:
                  - name: envoy.router
                    typed_config: {}
  clusters:
    - name: echo_service
      connect_timeout: 0.25s
      type: strict_dns
      lb_policy: round_robin
      load_assignment:
        cluster_name: echo_service
        endpoints:
          - lb_endpoints:
              - endpoint:
                  address:
                    socket_address: { address: 127.0.0.1, port_value: 8080 }

Restart Envoy:

sudo systemctl restart envoy

Then hit http://localhost in a browser or use curl:

curl http://localhost

You should see the directory listing from the Python server.

6. Tweak Envoy (Optional)

If you need TLS, rate limiting, or more advanced routing, dive into the official docs. But for most folks just having a reverse proxy in front of their services is enough.

That’s all there is to it. You now have a production‑ready Envoy instance on Ubuntu 20.04, ready to route traffic, load‑balance, and make your microservices talk nicely. If you hit snags, remember: check the logs (sudo journalctl -u envoy) and keep an eye out for port clashes.
